Hydraulic Power Packs
Custom Hydraulic Power Packs Manufacturer | HYDTI India
Hydrotronics Industries (HYDTI) designs and manufactures precision-engineered hydraulic power packs tailored for demanding industrial and mobile applications. Since 2005, we’ve delivered reliable hydraulic power units ranging from compact 15-liter systems to heavy-duty 3000-liter packs with motor capacities up to 100 HP and flow rates up to 400 LPM. Each power pack is built with high-quality pumps, motors, valves, and filtration systems to ensure consistent pressure control, durability, and long service life, even in harsh operating environments.
Get the best Hydraulic Power Pack tailored to your needs
Enquire TodayWhat Is a Hydraulic Power Pack?
A hydraulic power pack (also called a hydraulic power unit or HPU) is a self-contained system that generates, conditions, and controls pressurized hydraulic fluid to power cylinders, motors, and other hydraulic actuators. It is the central power source that enables your machinery to perform work lifting, pressing, forming, positioning, or moving loads with precision and control.
Core Components Working in Harmony:
- Hydraulic Reservoir – Stores fluid, dissipates heat, and allows contaminants to settle.
- Hydraulic Pump – Converts mechanical power into hydraulic flow (gear, vane, or piston pumps).
- Prime Mover – Electric motor or engine that drives the pump.
- Control Valves – Direct, regulate, and control fluid flow, pressure, and direction.
- Filtration System – Removes contaminants to protect components and extend fluid life.
- Instrumentation – Gauges, sensors, and indicators for monitoring and control.
- Heat Exchangers – Cooling systems to maintain optimal operating temperature.
HYDTI Hydraulic Power Pack Range and Capabilities
Comprehensive Specification
| Specification | Range | Application Fit |
|---|---|---|
| Tank Capacity | 15 Liters to 3000 Liters | From mobile equipment to large industrial installations |
| Motor Power | 0.25 HP to 100 HP | Precisely matched to your flow and pressure demands |
| Flow Rate | Up to 400 l/min | High-volume applications with rapid cycle times |
| Operating Pressure | Up to 6000 psi (414 bar) | High-pressure performancefor demanding operations |
| Tank Material | Mild Steel or Stainless Steel | Standard or corrosive-environment applications |
Control System Options
- Manual Lever Operated – Simple, reliable control for basic applications.
- Solenoid Operated (Semi-Automatic) – Electrically-activated directional control for improved efficiency.
- PLC Control (Fully Automatic) – Sophisticated automation with sequencing, monitoring, and feedback control.
Applications and Industries Served
- Industrial Manufacturing
- Mobile and Construction Equipment
- Material Handling Systems
- Steel Mills and Metal Processing
- Agriculture and Forestry
- Process Industries
- Testing and Simulation
